Large Inner Diameter Dissolvable Bridge Plug

Solving plug slip and small production channel in high-flow wells! Anti-slip structure + large inner diameter design,
“verification upon placement” integrated ball, fully dissolvable for high-flow production.
Ideal for oil & gas high-flow well fracturing and completion.

Main Advantage & Solution

1: Plugs slip in high-flow wellbores and lose zonal isolation effect;
Solution: Specialized anti-slip structure design, firm downhole fixation, no slip even in high-speed well fluid.
2: Small inner diameter plugs restrict high-flow well production;
Solution: Large inner diameter design, maximize well fluid flow channel, improve oil & gas production by 25%.
3: Separate ball deployment reduces high-flow well operation efficiency;
Solution: Integrated dissolvable ball, “verification upon placement”, no ground deployment, high-efficiency construction.

Parameter	Specification	Test Data/Note
Casing Size	4.5″ – 5.5″	High-flow well mainstream casing
Casing Inner Diameter	97.2-124.3mm	Precise fit for downhole casing
Working Differential Pressure	70 MPa	Multi-stage fracturing compatible
Working Temperature	30°C – 180°C	High-temperature high-flow well condition
Inner Diameter	≥30mm	Large inner diameter for high-flow production
Dissolvable Ball Size	35-38.5mm	Factory pre-matched, precise fit
Setting Force	10-16T	Anti-slip setting, firm fixation

For Oilfield Frac Service Companies: High-flow oil & gas well multi-stage fracturing and completion

For High-Yield Oilfield Enterprises: High-yield well zonal isolation and high-flow production

For Offshore Oil & Gas Enterprises: Offshore high-flow well fracturing plugging operations

For Equipment Distributors: High-flow well special anti-slip large inner diameter plug supply

We provide our customers with high-quality, reliable solutions backed by robust engineering and fast response capabilities.

We offer machining and contract manufacturing services based on your design drawings,
The formulation can be adjusted based on well conditions
