PLC-Controlled Intelligent Valve Test Bench with Pressure Curve Monitoring & Data Reporting System

PLC touch screen intelligent valve test bench supports parameter setting, automatic process control and real-time pressure curve monitoring. It automatically completes water filling, pressurization, pressure holding and pressure relief with pressure self-locking protection. It realizes automatic data acquisition, curve drawing and report generation with full traceability, meeting API and national standard factory inspection requirements.

Downloads

Main Advantage

Full automatic control by PLC & computer: automatic clamping, pressurizing, holding, relief and reset without manual attendance.
Real-time data acquisition, pressure curve plotting and automatic report generation with full traceable test data.
Double-end hydraulic clamping with high concentricity and stability; equipped with overpressure protection, leakage alarm and emergency stop for high safety.

Application

Large-scale valve manufacturing factory, automatic valve production line, export valve certification center, third-party inspection laboratory, petrochemical large-diameter valve testing, power plant high-pressure valve inspection, marine engineering valve testing, pipeline engineering valve quality inspection.

All-Weather Adaptability

Industrial PLC control with strong anti-interference for long-term mass production; accessible to workshop LAN for network data storage, suitable for intelligent factory quality inspection station.

Technical Parameters

Item	Specifications
Control System	PLC + Touch Screen / Computer
Test Pressure	1.6–40MPa
Applicable Diameter	DN50–DN600mm
Auto Functions	Clamp / Pressurize / Hold / Relief automatically
Data Function	Real-time curve, recording, automatic report
Compliance	API 598, ISO, GB/T 13927
Safety Device	Overpressure protection, leakage alarm, emergency stop
