Plunger Metering Pump

JPX
2J-X
JPZ
JPR
JPD
JPD

JPX

Main Parameter:

Flow range: 1-230LPH@50Hz/1.2-276LPH@60Hz
Pressure range: 1-400 Bar
Power: 0.37kw IEC71 4 pole Motor
Material: SS304; SS316, others on request

Parameter Table:

Model	50Hz		60Hz		pressure (MPa)	Piston Size	Stroke Length (mm)	Motor Power (KW)	Connection
Model	Flow Rate (L/H)	PUMP Speed (SPM)	Flow Rate (L/H)	Pump Speed (SPM)		Dia (mm)
JPX1/40	1	96	1.2	115	40	6	10	0.37	DN6 union for welding
JPX2/40	2		2.4		40	6	20
JPX5/33	5		6		33	8
JPX8/21	8		9.6		21	10
JPX12/15	12		14		15	12
JPX20/8	20		24		8	16			DN10 union for welding
JPX33/5	33		40		5	20
JPX52/3.3	52		62		3.3	25
JPX65/2.6	65		78		2.6	28
JPX88/2.1	88		106		2.1	32
JPX105/1.7	105		126		1.7	35
JPX125/1.4	125		150		1.4	38			DN15 union for welding
JPX155/1.1	155		186		1.1	42
JPX190/1.1	190	144	228	173	1.1	38
JPX230/1.0	230	144	276	173	1	42

2J-X

Main Parameter:

Flow range: 5-300LPH@50Hz/6-360LPH@60Hz
Pressure range: 1-400 Bar
Power: 0.37kw IEC71 4 pole Motor
Material: SS304; SS316, others on request

Parameter Table:

Model	50Hz		60Hz		pressure (MPa)	Piston Size	Stroke Length (mm)	Motor Power (KW)	Connection
Model	Flow Rate (L/H)	PUMP Speed (SPM)	Flow Rate (L/H)	Pump Speed (SPM)	pressure (MPa)	Dia (mm)	Stroke Length (mm)	Motor Power (KW)	Connection
2J-X5/40	5	96	6	115	40	6	20	0.37	DN6 union for welding
2J-X8/32	8		9.6		32	8
2J-X16/20	16		19		20	10
2J-X25/14	25		30		14	12			DN8 union for welding
2J-X40/5.4	40		48		5.4	16
2J-X60/3.5	60		72		3.5	20
2J-X100/2.2	100		120		2.2	25			DN10 union for welding
2J-X130/1.7	130		156		1.7	28
2J-X160/1.3	160		192		1.3	32
2J-X200/1.0	200		240		1	35
2J-X250/0.8	250		300		0.8	38
2J-X300/0.6	300		360		0.6	42

JPZ

Main Parameter:

Flow range: 6-600LPH@50Hz/7.2-720LPH@60Hz
Pressure range: 8-500 Bar
Power: 0.75kw IEC80 4 pole Motor
Material: SS304; SS316, others on request

Parameter Table:

Model	50Hz		60Hz		pressure (MPa)	Piston Size	Stroke Length (mm)	Motor Power (KW)	Connection
Model	Flow Rate (L/H)	Pump Speed (SPM)	Flow Rate (L/H)	Pump Speed (SPM)	pressure (MPa)	Dia (mm)	Stroke Length (mm)	Motor Power (KW)	Connection
JPZ6/50	6	7.2	96	50	115	8	25	0.75	DN6 union for welding
JPZ10/45	10	12		45		10
JPZ15/30	15	18		30		12
JPZ26/17	26	31		17		16			DN10 union for welding
JPZ42/10	42	50		10		20
JPZ66/7	66	79		7		25
JPZ85/5.5	85	102		5.5		28
JPZ110/4.0	110	132		4		32
JPZ135/3.3	135	162		3.3		35			DN15 union for welding
JPZ160/2.8	160	192		2.8		38
JPZ200/2.3	200	240		2.3		42
JPZ225/2.0	225	270		2		45
JPZ280/1.7	280	336		1.7		50
JPZ335/1.3	335	402		1.3		55			DN25 Flange (HG/T20592 RF)
JPZ400/1.1	400	480		1.1		60
JPZ500/1.0	500	600		1		55
JPZ600/0.8	600	720		0.8		60

Duplex or Triplex head is available.

JPR

Main Parameter:

Flow range: 18-1620LPH@50Hz/22-1944LPH@60Hz
Pressure range: 7-500 Bar
Power: 1.5kw IEC90 4 pole Motor
Material: SS304; SS316, others on request

Parameter Table:

Model	50Hz		60Hz		Pressure (MPa)	Piston Size	Stroke Length (mm)	Motor Power (KW)	Connection
Model	Flow Rate (L/H)	Pump Speed (SPM)	Flow Rate (L/H)	Pump Speed (SPM)	Pressure (MPa)	Dia (mm)	Stroke Length (mm)	Motor Power (KW)	Connection
JPR18/50	18	96	22	115	50	12	30	1.5	DN10 union for welding
JPR32/31	32		38		31	16
JPR52/20	52		62		20	20
JPR80/12	80		96		12	25
JPR100/10	100		120		10	28
JPR135/8	135		162		8	32			DN15 union for welding
JPR160/6.5	160		192		6.5	35
JPR190/5.5	190		228		5.5	38
JPR232/4.5	232		278		4.5	42
JPR268/4.0	268		322		4	45
JPR332/3.2	332		398		3.2	50
JPR400/2.5	400		480		2.5	55			DN25 Flange (HG/T20592 RF)
JPR480/2.2	480		576		2.2	60
JPR565/1.8	565		678		1.8	65
JPR655/1.6	655		786		1.6	70
JPR750/1.4	750		786		1.4	75
JPR855/1.2	855		1026		1.2	80			DN40 Flange (HG/T20592 RF)
JPR965/1.0	965		1158		1	85
JPR1080/0.9	1080		1296		0.9	90
JPR1280/0.9	1280	144	1536	173	0.9	80
JPR1450/0.8	1450		1740		0.8	85
JPR1620/0.7	1620		1944		0.7	90

Duplex or Triplex head is available.

JPD

Main Parameter:

Flow range: 30-3720LPH@50Hz/36-4464LPH@60Hz
Pressure range: 3kw/4KW 4 pole Motor
Power: 3kw IEC100 4 pole Motor
Material: SS304; SS316, others on request

Parameter Table:

Model	50Hz		60Hz		Pressure (MPa)			Piston Size	Stroke Length (mm)	Connection
Model	Flow Rate (L/H)	Pump Speed (SPM)	Flow Rate (L/H)	Pump Speed (SPM)	5.5KW	7.5KW	11KW	Dia (mm)	Stroke Length (mm)	Connection
JPT85/50	85	96	102	115	50	/	/	16	80	DN15 Flange (HG/T20615 TG)
JPT135/(50/36)	135		162		36	50	/	20
JPT218(50/32/23)	218		262		23	32	50	25
JPT275(40/25/19)	275		330		19	25	40	28
JPT360(30/20/14)	360		432		14	20	30	32		DN25 Flange (HG/T20615 TG)
JPT510(21/14/10)	510		612		10	14	21	38
JPT620(18/12/8.5)	620		744		8.5	12	18	42
JPT885(12/8.2/6.0)	885		1062		6	8.2	12	50
JPT1070(10/6.8/5.0)	1070		1284		5	6.8	10	55		DN40 Flange (HG/T20615 TG)
JPT1280(8.7/5.6/4.1)	1280		1536		4.1	5.6	8.7	60
JPT1500(7.5/4.9/3.5)	1500		1800		3.5	4.9	7.5	65
JPT1750(6.5/4.2/3.0)	1750		2100		3	4.2	6.5	70
JPT2000(5.5/3.7/2.6)	2000		2400		2.6	3.7	5.5	75
JPT2300(4.8/3.2/2.3)	2300		2760		2.3	3.2	4.8	80
JPT2600(4.3/2.9/2.0)	2600		3120		2	2.9	4.3	85
JPT2900(3.8/2.5/1.8)	2900		3480		1.8	2.5	3.8	90		DN50 Flange (HG/T20592 RF)
JPT3230(3.5/2.3/1.6)	3230		3876		1.6	2.3	3.5	95
JPT3600(3.1/2.1/1.5)	3600		4320		1.5	2.1	3.1	100
JPT4350(2.6/1.7/1.2)	4350		5220		1.2	1.7	2.6	110
JPT5200(2.2/1.4/1.0)	5200		6240		1	1.4	2.2	120		DN65 Flange (HG/T20592 RF)
JPT6050(1.8/1.2/0.9)	6050		7260		0.9	1.2	1.8	130
JPT7050(1.6/1.0/0.8)	7050		8460		0.8	1	1.6	140
JPT8100(1.4/0.9/0.7)	8100		9720		0.7	0.9	1.4	150		DN80 Flange (HG/T20592 RF)
JPT9200(1.2/0.8/0.6)	9200		11040		0.6	0.8	1.2	160
JPT10400(1.1/0.7/0.5)	10400		12480		0.5	0.7	1.1	170
JPT11600(0.9/0.6/0.5)	11600		13920		0.5	0.6	0.9	180		DN100 Flange (HG/T20592 RF)
JPT13000(0.8/0.6/0.4)	13000		15600		0.4	0.6	0.8	190
JPT14300(0.7/0.5/0.4)	14300		17160		0.4	0.5	0.7	200

Duplex or Triplex head is available.

JPD

Main Parameter:

Flow range: 85-14300LPH@50Hz/102-17160LPH@60Hz
Pressure range: 4-500 Bar
Power: 5.5kw/7.5kw/11kw 4 pole Motor
Material: SS304; SS316, others on request

Parameter Table:

Model	50Hz		60Hz		Pressure (MPa)			Piston Size	Stroke Length (mm)	Connection
Model	Flow Rate (L/H)	Pump Speed (SPM)	Flow Rate (L/H)	Pump Speed (SPM)	5.5KW	7.5KW	11KW	Dia (mm)	Stroke Length (mm)	Connection
JPT85/50	85	96	102	115	50	/	/	16	80	DN15 Flange (HG/T20615 TG)
JPT135/(50/36)	135		162		36	50	/	20
JPT218(50/32/23)	218		262		23	32	50	25
JPT275(40/25/19)	275		330		19	25	40	28
JPT360(30/20/14)	360		432		14	20	30	32		DN25 Flange (HG/T20615 TG)
JPT510(21/14/10)	510		612		10	14	21	38
JPT620(18/12/8.5)	620		744		8.5	12	18	42
JPT885(12/8.2/6.0)	885		1062		6	8.2	12	50
JPT1070(10/6.8/5.0)	1070		1284		5	6.8	10	55		DN40 Flange (HG/T20615 TG)
JPT1280(8.7/5.6/4.1)	1280		1536		4.1	5.6	8.7	60
JPT1500(7.5/4.9/3.5)	1500		1800		3.5	4.9	7.5	65
JPT1750(6.5/4.2/3.0)	1750		2100		3	4.2	6.5	70
JPT2000(5.5/3.7/2.6)	2000		2400		2.6	3.7	5.5	75
JPT2300(4.8/3.2/2.3)	2300		2760		2.3	3.2	4.8	80
JPT2600(4.3/2.9/2.0)	2600		3120		2	2.9	4.3	85
JPT2900(3.8/2.5/1.8)	2900		3480		1.8	2.5	3.8	90		DN50 Flange (HG/T20592 RF)
JPT3230(3.5/2.3/1.6)	3230		3876		1.6	2.3	3.5	95
JPT3600(3.1/2.1/1.5)	3600		4320		1.5	2.1	3.1	100
JPT4350(2.6/1.7/1.2)	4350		5220		1.2	1.7	2.6	110
JPT5200(2.2/1.4/1.0)	5200		6240		1	1.4	2.2	120		DN65 Flange (HG/T20592 RF)
JPT6050(1.8/1.2/0.9)	6050		7260		0.9	1.2	1.8	130
JPT7050(1.6/1.0/0.8)	7050		8460		0.8	1	1.6	140
JPT8100(1.4/0.9/0.7)	8100		9720		0.7	0.9	1.4	150		DN80 Flange (HG/T20592 RF)
JPT9200(1.2/0.8/0.6)	9200		11040		0.6	0.8	1.2	160
JPT10400(1.1/0.7/0.5)	10400		12480		0.5	0.7	1.1	170
JPT11600(0.9/0.6/0.5)	11600		13920		0.5	0.6	0.9	180		DN100 Flange (HG/T20592 RF)
JPT13000(0.8/0.6/0.4)	13000		15600		0.4	0.6	0.8	190
JPT14300(0.7/0.5/0.4)	14300		17160		0.4	0.5	0.7	200

Duplex or Triplex head is available.
