Portable Gas Pressure Intensifier
The portable gas pressure intensifier adopts a handheld design, weighing only 5kg. It is a lightweight device specially designed for on-site emergency boosting and small equipment testing. No complex installation is required—just connect the gas source to use. It is suitable for scenarios such as outdoor emergency repair, on-site airtightness detection, and small valve pressure testing, providing a convenient high-pressure gas source solution for mobile operations.
Main Advantage
Application
Airtightness testing for outdoor pipeline emergency repair, on-site pressure testing of small valves, emergency high-pressure gas source for vehicle-mounted pneumatic equipment, air pressure testing for elevator maintenance, airtightness detection of fire-fighting equipment, pressure testing of home appliances (e.g., water purifiers).
All-Weather Adaptability
The shell adopts IP54 waterproof design, enabling temporary use outdoors in rainy days; operating temperature range of -5℃~+45℃, adapting to most outdoor normal-temperature operation environments; equipped with a shockproof protective cover to avoid collision damage during movement, improving equipment durability.
Technical Parameters
| Item | Specifications |
| Model | GPI-M Series (Customizable) |
| Inlet Pressure Range | 0.3~0.8MPa |
| Outlet Pressure Range | 1~8MPa (Customizable up to 12MPa) |
| Pressure Ratio | 1:3 / 1:5 / 1:10 (Optional) |
| Medium | Compressed Air, Nitrogen |
| Drive Mode | Pneumatic |
| Operating Temperature | -5℃~+45℃ |
| Material | Engineering Plastics (Shell) + Aluminum Alloy (Internal Components) |
| Weight | ≤5kg |
| Connection Interface | Quick Connector (G1/4″) |
We offer customization of handheld structure (e.g., ergonomic handle), waterproof grade (up to IP65), and quick connector specifications to match your on-site mobile boosting needs.
