Standard Pneumatic-Driven Air Amplifier
This is a single-stage pneumatic-driven gas pressure intensifier with oil-free lubrication design. It can boost low-pressure gases such as compressed air and nitrogen to higher pressures. Featuring a compact structure and no electrical components, it is suitable for gas pressure boosting in industrial sites without power supply. It is widely used with pressure test systems and airtightness detection devices to provide stable high-pressure gas sources for various pneumatic equipment.
Main Advantage
Application
High-pressure gas supply for pneumatic tools, gas source boosting for pressure test systems, auxiliary boosting for airtightness detection devices, high-pressure gas source for valve/pipeline leakage testing, power enhancement for pneumatic actuators, gas pressure adjustment in laboratories.
All-Weather Adaptability
Operating temperature range of -20℃~+60℃, enabling stable operation in extreme environments such as low-temperature outdoors and high-temperature workshops; small size (approximately 400×250×300mm) supports wall-mounted or floor-mounted installation, suitable for deployment in narrow spaces.
Technical Parameters
| Item | Specifications |
| Model | GPI-S Series (Customizable) |
| Inlet Pressure Range | 0.3~0.8MPa |
| Outlet Pressure Range | 2~10MPa (Customizable up to 15MPa) |
| Pressure Ratio | 1:5 / 1:10 / 1:15 (Optional) |
| Medium | Compressed Air, Nitrogen, Argon (Inert Gas) |
| Drive Mode | Pneumatic (No Power Supply) |
| Operating Temperature | -20℃~+60℃ |
| Material | Aluminum Alloy (Shell) + Stainless Steel (Internal Components) |
| Connection Interface | G1/2″ (Inlet) / G1/4″ (Outlet) |
We provide customization of pressure ratio (up to 1:20), interface specifications (e.g., NPT, BSP), and high-temperature resistant materials to match your specific gas boosting needs.
