Ultra-High Pressure Horizontal Valve Test Bench for Gate Valve & Ball Valve

Ultra-high pressure horizontal test bench is applicable for strength and tightness test of straight flanged valves such as gate valve, globe valve and ball valve. It adopts end-face top-pressure clamping structure to fix the valve evenly. Optional sealing disk supports testing for welded and threaded end valves, complying with API 598 and national standards.

Request a Quote Downloads

Main Advantage

  • Integral welded rigid frame with high stability, no deformation under high pressure and long service life.
  • Hydraulic end clamping with self-centering function, fast clamping and reliable sealing without damaging valve flange face.

Application

Valve manufacturing factory, petrochemical plant, natural gas pipeline project, power station valve inspection, oil pipeline maintenance, municipal water supply & drainage, export valve certification laboratory, industrial pipeline valve testing, marine valve inspection.

All-Weather Adaptability

Horizontal floor structure with heavy load capacity, suitable for long-term fixed workshop station; compatible with water, air and hydraulic oil, suitable for mass factory valve pressure testing.

Technical Parameters

ItemSpecifications
Test Pressure1.6–32MPa (customizable up to 150MPa)
Applicable DiameterDN50–DN600mm
Clamping TypeHydraulic end clamping
Test MediaWater, Air, Hydraulic Oil
ComplianceAPI 598, GB/T 13927, ISO

Custom pressure grade, maximum valve diameter and medium system can be designed for large-diameter high-pressure valve production lines.
